PowerUP spare parts suitable for MWM® engines

PowerUP Cylinder Head suitable for MWM® TCG2016 engines

• PowerUP has developed valves, seat rings and guides to reduce wear and improve reliability and service life.
• Improved spark plug cooling concept positively influences the service life of the spark plugs
• Increased safety and lower service costs thanks to our two-piece plug and connector design with trip protection.
• Improved serviceability due to easily accessible thermocouple bore and range hole (no need to remove the valve cover)

• Specifically designed for the highest compatibility
• It can be installed together with the manufacturer’s original cylinder heads
• It is available for numerous versions of the MWM® TCG 2016 and various gas types
• Plug & Play upgrade solution

Cylinder head overhaul for MWM® type engines 2016 and 2020

PowerUP offers the necessary spare parts as well as professional overhauling of original cylinder heads of types MWM® 2016 and 2020.

Our portfolio ranges from condition based overhaul with maximum re-usage of qualified parts up to a full overhaul including re-machining of all relevant surfaces, thourough cleaning, exchange of all wear parts with PowerUP developed parts and painting.

Advantages

• Highly reduced cost for cylinder head exchange
• Highest quality PowerUP valves, seat rings and valve guides

Blowby Filter suitable for MWM® engines

Our blow-by filtration system, suitable for MWM® engines, can reduce the soiling of turbochargers, charge air coolers and combustion chambers, thereby contributing to the service life and performance stability of the gas engine.

This improves the operational reliability of the system; in addition, the blow-by filtration system is designed for a long service life.

Advantages

• Expected lifetime up to 30.000 operating hours
• Oil separation efficiency of up to 99.98%
• Easy install and maintenance free

Compatibility

• Easy to install retrofit-solution for MWM® 2016 & 2020 engines
• Compatible with all known OEM versions

Pistons suitable for MWM® engines

We offer the entire product line of pistons suitable for MWM® gas engines for all compression ratios and gas-types.

Additionally, a retrofit solution with cylinder liners featuring an anti-polishing ring is available, which can contribute to improved performance and reliability depending on the application.

Advantages

• Improved piston bowl design to support higher squish piston reliability and reduce the risk of piston cracking
• PowerUP designed piston has lower piston bowl temperatures, thus decreasing knocking probability

Cylinder liners with anti-polishing ring suitable for MWM® engines

Our cylinder liners with anti-polishing ring can contribute to the reliability of your MWM® engine by reducing carbon deposits on the upper part of the piston. This can reduce the risk of wear on the cylinder liner and damage to the upper ring.

They are also available as an upgrade solution in combination with squish-pistons for engine versions without anti-polishing ring.

Spark Plugs suitable for MWM® engines

The spark plug developed by PowerUP, suitable for MWM® engines, is designed for high reliability thanks to its robust ring electrode design.

It also helps in cutting service costs due to our two-piece design with a separate spark plug connector.

Advantages

• The robust ring electrode design supports high reliability and resistance to early failures
• Improved heat transfer & high-grade electrode material to ensure long lifetime
• Two-piece design enables separate exchange of spark plug and connector to reduce service costs

Compatibility

• Compatible with all MWM® 2016 & 2020 engines through our plug & play design
• Compatible with natural gas & biogas

Maintenance Parts suitable for MWM® engines

The PowerUP product range, suitable for MWM^® engines

PowerUP offers the full range of suitable consumables & spare parts for preventive & corrective maintenance for MWM^® engines. Our offer ranges from consumables up to minor & major overhauls and even an upgrade of the engine control system. Each PowerUP part is thoroughly specified and sourced from reliable, well-known suppliers to meet the highest quality standards!
